Plastic Tip Tweezers

MATERIAL TECHNICAL DATA SHEETS

PLASTICS

Engineering plastic type CF

  • PA66/CF30 polyamide 66 reinforced with 30 wt% carbon fibre
  • heat stabilized
  • very high rigidity, excellent tensile and flexural strength, fatigue and creep resistance
  • low friction, self lubricating properties, excellent wear and abrasion resistance
  • Good heat capability
  • good chemical resistance (oils, grease, fuels, non polar solvents); not resistant to strong acids, alkalis and hot water or steam
  • ESD safe material, (avoids dust attraction, sparks generation, ignition sources)
  • very low coefficient of linear thermal expansion
  • typical applications include handling of sensitive components and devices (electronic components, micromechanical parts, glass and ceramic substrates, capillary, etc.)

High-performance plastic type CP

  • PEEK/CF30 polyetheretherketone reinforced with 30 wt% carbon fibre
  • very hard, rigid, high tensile and flexural strength, very high wear resistance
  • high heat capability (260-300°C), good dimension stability, low thermal linear expansion coefficient
  • excellent resistance to chemicals, aggressive agents and to thermal ageing
  • ESD material, low surface resistivity (105 Ohm)
  • typical applications include handling of components in cleaning/chemical/assembly processes also at high temperatures (soldering)

Engineering plastic type DG/DL

  • POM/GF30 acetal resin reinforced with 30 wt% glass fibre
  • good tensile and flexural strength, fatigue and creep resistance
  • low friction, good wear and abrasion resistance
  • low moisture absorption
  • good chemical resistance (oils, grease, fuels, organic solvents); not resistant to strong acids, alkalis and oxidizing agents; good hydrolytic resistance (hot water)
  • insulating
  • typical applications include handling of very scratch sensitive components

High performance plastic type SV

  • PVDF polyvinylidene fluoride carbon fibre reinforced
  • excellent mechanical strength and toughness
  • smooth surface
  • heat stabilized, high heat capability, continuous use temperature up to 150°C
  • high purity (clean room and medical devices approved, low extraction value)
  • excellent chemical resistance to most aggressive substances (mineral and organic acids) and solvents (hydrocarbons, alcohols, halogenated), resistant to halogens
  • outstanding resistance to hydrofluoric acid (40% conc., 90°C), nitric acid (50% conc., 90°C), hydrochloric acid (36% conc., 90°C)
  • high abrasion resistant
  • resistant to UV and nuclear radiation (sterilisation)
  • ESD safe (avoids dust attraction, sparks generation, ignition sources)
  • typical applications include handling of very scratch- and contamination-sensitive components, cleaning and etching processes
